ZENORO PREMIUM: Custom build | Exhaust treatment

ZENORO PREMIUM:
Custom build | Exhaust treatment

Premium marine generators

Zenoro Premium utilizes high-end components and smart design to achieve excellent reliability and comfort. This generator is the silent beating heart of all comfort on board of your yacht. The Zenoro Premium is available in a wide ekW range. We provide customization based on your requirements and can offer standards of any classification society.

Valuable customization options are:
• Exhaust after treatment systems (DPF and/or SCR) integration to obtain IMO Tier III emission, from our partner Xeamos.
• Waste heat recovery can be built into the sound box for more efficient energy use and to select a smaller size generator set.
• Single elastic mounting or even our solution for ultimate comfort: double elastic mounting.

Technical specifications

Dimensions | Compact

Weight | Yacht standard

Sound reduction | Equal or > than 20 dB(A) at 1 meter free field conditions

Vibrations | High-end isolators

Power | Frequency: 50 Hz and 60 Hz
ekW:  55 up to 515 ekW

Emission | IMO exempted,

IMO Tier II and/or IMO Tier III

Colours | RAL 9010 or custom

Enclosure | Aluminium modular design

Class Certification | All mayor class societies

Engine controller
ComAp marine approved digital engine controller panel to control and engine protection. Compatible with any modern generator controller, allows REMOTE SPEED BIAS voltage or current control.

Many engine and generator functions are available for ship monitoring systems.
Alternator - Leroy somer or stamford (optional)
Alternators meet the requirements of Maritime environment. They are type approved and standard equipped with a new digital AVR which allows easy configure and monitor, a regulation accuracy of +/- 0,25% is acquired.
Xeamos after treatment system
Xeamos electrical Zero Soot system, integrated heater, flat or normal version available.
John Deere Marine engine
Modern common rail fuel systems and factory marinated engine. One-side serviceability of fuel, oil filters and air filter.
Quit and low vibrations
Standard: single elastic, optional with rubber design
Optional: double elastic with 2 layers of rubber design
Customer connections
Customised penetrations for water and fuel
Stamford alternator (optional)
Stamford, PMG excitation, the best alternator in class, long lifetime, reliable AVR 321/341
Soundown mixer (optional)
Optional integrated mixer and water separator
Previous slide
Next slide
Zenoro Premium Marine Generators

Engine controller

ComAp marine approved digital engine controller panel to control and engine protection. Compatible with any modern generator controller, allows REMOTE SPEED BIAS voltage or current control.

Alternator - Leroy somer or stamford (optional)

Alternators meet the requirements of Maritime environment. They are type approved and standard equipped with a new digital AVR which allows easy configure and monitor, a regulation accuracy of +/- 0,25% is acquired.



Xeamos after treatment system

Xeamos electrical Zero Soot system, integrated heater, flat or normal version available.

John Deere Marine engine

Modern common rail fuel systems and factory marinated engine. One-side serviceability of fuel, oil filters and air filter.

John Deere fuel filters

Duplex switchable final fuel filters.

Quit and low vibrations

Standard: single elastic, optional with rubber design.
Optional: double elastic with 2 layers of rubber design.

Customer connections

Customised penetrations for water and fuel.

(in the back)

Stamford alternator (optional)

Stamford, PMG excitation, the best alternator in class, long lifetime, reliable AVR 321/341

Soundown mixer (optional)

Optional integrated mixer and water separator.

More information?
Please contact us:
sales@zenoro.com
+31 (0)486 201 600

Zenoro Premium products are engineered and assembled in the Netherlands, which enables a fast lead-time for both your new-built and refit projects. Please contact your local Zenoro partner for a quote, details and lead times.

Our generators are always factory load tested and optional classified by all classification societies as Lloyds, ABS, BV, GL-DNV, Rina and others.

The ‘sound enclosure’ is powder coated in RAL 9010 and created with aluminum extrusion profiles and heavy-duty corner blocks. Sandwich panels with sound insulation material, non-combustible top layer resistant for high temperatures fuel, water, oil proof. Latches on every removable panel allows easy service. For major service jobs our sound-enclosure offers easy disassembly and assembly. Esthetic, Stiffness and robust design fulfills a ‘’yacht’’ look and feel. Panels are available in zincor or full aluminium.

  • Air inlet box and air outlet box
  • Air inlet and air outlet, on request at customized positions. Both are equipped with smart coulisse design, double or single coulisse


A carrying frame for an on top located exhaust aftertreatment system (DPF and/or SCR) from our partner Xeamos can be opted, which allows easy integration, esthetic design and easy access for service. Both electrical and fuel burner DPF system can be integrated in the design.

For high durability and easy cleaning, a Zenoro Premium Generator has a stainless steel baseplate.

We provide our optimum enclosure design, based on 10 years of experience as a manufacturer of generator sets. Noise levels are available on request.

  • Standard: optimum soft 40 shore rubber mounts.
    On request: rubber design mounts for single and double elastic mounting, for ultimate comfort.
  • A unique divider / slide plate system separates and controls the engine (hot) and alternator (colder) area. Therefore, no electrical fan is required. Air outlet and inlet position avoid recirculation.

Both Leroy Somer and Stamford marine alternators are available in various voltages. Zenoro Premium also provides oversized execution and options for various AVR models and/or additional bearing or winding temperature sensors.

Standard durable sensors are used for oil temperature and loss of coolant. Extra add-on sensors are available for all classification requirements and/or for the comfort of the crew on board.

Water, fuel, exhaust and electrical connections can be selected in standard or customized position (for example in the baseplate).

Waste heat recovery can be built into the sound box for more efficient energy use and a smaller footprint.

To allow an easy integration per layout of your yacht, we can arrange remote generator sets. These sets contain mirrored fuel filters, a loose controller box and a mirrored variant of the exhaust after treatment system, located on top of the generator set.
